JEP34‐VF‐NBR
Pump with built-in frequency variator
Applications: Diesel, oil, wine, liquid foods, chemicals and cosmetics, pharmaceutical
Pump with built-in frequency variator
Descriptive
Technical data:
- Voltage: single-phase 230 Volts
- Power: 0.56
- Voltage: single-phase 230 Volts
- Current: 3 A
- Rotation speed: 285 to 1400 rpm
- Max. flow rate: 0.27 to 1.6 m3/h
- Max. TDH: 12 to 24
- Max. viscosity: 500 to 1500 cPo
Specifications and advantages:
- Pump with built-in frequency variator
Characteristics
| Fluid | Diesel, Oil, Food liquids, Chemical liquids, Cosmetic liquids, Pharmaceutical liquids, Wine |
|---|---|
| Technology | Flexible impeller |
| ATEX | No |
| Pump | Bare |
| Max flow rate | 0.27 to 1.6 m3/h |
| Orifice | 3/4’’ M |
| Materials | Stainless steel |
| Mechanism | NBR impeller |
