JEX114C1, JEX114C2, JEX112C2
Electric side-channel pumps with DC motor
Applications: Chemical liquids, fertilizers, sea water, milk, wine, oil, fruit juice
Electric side-channel pumps with DC motor
Descriptive
Technical data:
- Pump with low-voltage motor, stainless steel 316 body
- Liquid foods, industrial and chemical liquids without solid impurities.
- Voltage: 12 Volts (JEX114C1), 24 Volts (JEX114C2, JEX112C2)
- Rotation speed: 2000 rpm, 1400 rpm
- Power: 0.37, 1.12 (JEX112C2)
- Voltage: 12 V dc (JEX114C1), 24 V dc
- Current: 32 A (JEX114C1), 20 A (JEX114C2), 45 A (JEX112C2)
- Orifice Ø: 1"1/4 M, 1"1/2 M (JEX112C2)
- Max. TDH: 10 metres, 22 metres (JEX112C2)
Specifications and advantages:
- Electric side-channel pump with DC motor
Characteristics
| Fluid | Seawater, Fertilizers, Oil, Juice, Milk, Chemical liquids, Wine |
|---|---|
| Technology | DC, Side channel |
| ATEX | No |
| Pump | Bare |
| Max flow rate | 3,5 m3/h - 7,2 m3/h |
| Orifice | 1"1/4 M, 1"1/2 M |
| Materials | Stainless steel 316 |
| Mechanism | Stainless steel 316 |
