F-INOX1000-700EX, F-INOX1000-D600EX

Electric barrel-emptying pumps

Applications: Transfer of petrol, alcohol, thinners, flammable solvents

Need advice?

Contact us

Electric barrel-emptying pumps


Atex Pump marking: ATEX 94/9/CE ATEX II 2G IIB T3.

Technical data

  • Pump compliant with ATEX standard 94/9/EC ATEX II 2G IIB T3
  • Max. temperature: 100°C
  • Max. viscosity: 800 cP
  • Max. density: 1.6
  • Motor: single-phase 230 V, 50 Hz, 700 W with 5 m of cable and On-Off switch
  • IP 54 and non-Atex plug
  • Pneumatic motor: 600 W
  • Pump/motor coupling: 1/8 turn quick connector
  • Probe length: 1000 millimetres
  • Outer Ø: 40 millimetres
  • Max. density: 1.6
  • Max. TDH: 7 metres (F-INOX1000-700EX), 8 m (F-INOX1000-D600EX)

Specifications and advantages:

  • Electric barrel-emptying pump


More Information
Fluid Alcohol, Diluants, Petrol, Flammable solvents
Technology Turbine
Pump marking ATEX 94/9/CE ATEX II 2G IIB T3
Pump Bare
Max flow rate 120 l/min - 135 l/min
Materials Stainless steel
Mechanism Stainless steel

Available options

  • Immersion tube 700, 1200 mm or custom-made.

  • Other materials or pipe Ø on request
