PP1/2SAN
Pneumatic membrane pump, PP body
Applications: Water-based liquid, acid or diluted base, AdBlue, etc.
Pneumatic membrane pump, PP body
Descriptive
Specifications and advantages
- Specially designed to transfer aggressive and/or viscous chemical liquids.
- Plastic pumps have to be used for the pumping and transferring of strong acids or bases. These pumps are self-priming when used for dry running.
- The priming height varies depending on the humidity of the pump.
- The flow rate can be set by adjusting the pressure and flow rate of intake air.
- Dry running is possible for this pump: it will continue to run without overheating or wear.
- The pump has a special safety mechanism: automatic shutdown if the delivery of liquid is stopped.
Characteristics
| Fluid | Acid, Adblue, Water |
|---|---|
| Technology | Membrane |
| ATEX | No |
| Pump | Bare |
| Max flow rate | 50l/min |
| Orifice | 1/2’’ |
| Materials | Polypropylene |
| Balls | PTFE |
| Sockets | PP |
| Other contact parts | Stainless steel, EPDM |
| Max. viscosity | 5000 cPo |
| Pressure | 8 bars |
| Dry membrane | 6 m |
| Wet membrane | 8 m |
| Air consumption | from 3 to 22 Nm3/h |
| Membrane | Santoprene® |
| Particles | 3mm |
