F-PP1000-520, F-PP1000-D600
Electric barrel-emptying pumps
Applications: Mild acids, mild bases
Electric barrel-emptying pumps
Descriptive
Technical data
- Designed for transferring mild acids or mild bases
- Max. temperature: 50°C
- Motor: single-phase 230 V, 50 Hz, 520 W with 5 metres of cable and On-Off switch. IP 24
- Pneumatic motor: 600 W
- Pump/motor coupling: 1/8 turn quick connector
- Probe length: 1000 millimetres
- Outer Ø: 40 millimetres
- Motors: electric (F-PP1000-520), Pneumatic (F-PP1000-D600)
- Density: 1.3 (F-PP1000-520), 1.6 (F-PP1000-D600)
- Max. viscosity: 300 cP (F-PP1000-520), 800 cP (F-PP1000-D600)
- Construction: PP / stainless steel 1.4571
- Max. TDH: 6 metres
Specifications and advantages:
- Electric barrel-emptying pump
Characteristics
| Fluid | Acid / Base, Water with low solids contect |
|---|---|
| Technology | Barrel-emptying, Turbine |
| ATEX | No |
| Pump | Bare |
| Max flow rate | 90 l/min - 100 l/min |
| Orifice | 1"1/4 M |
| Materials | PP |
| Mechanism | Stainless steel |
