F-PVDF1000-520, F-PVDF1000-D600
Electric barrel-emptying pumps
Applications: Strong acids, strong bases, aggressive fluids
Electric barrel-emptying pumps
Descriptive
Technical data
- Max. temperature: 80°C
- Single-phase motor: 230 V, 50 Hz, 520 W with 5 m of cable and On-Off switch. IP 24
- Pneumatic motor: 600 W
- Pump/motor coupling: 1/8 turn quick connector
- Probe length: 1000 millimetres
- Outer Ø: 40 millimetres
- Density: 1.3 (F-PVDF1000-520), 1.6 (F-PVDF1000-D600)
- Max. viscosity: 300 cP (F-PVDF1000-520), 800 cP (F-PVDF1000-D600)
- Max. TDH: 6 metres (F-PVDF1000-520), 7 metres (F-PVDF1000-D600)
- Construction: PVDF, hastelloy C
Specifications and advantages:
- Electric barrel-emptying pump
Characteristics
| Fluid | Acid / Base, Water with low solids contect |
|---|---|
| Technology | Turbine |
| ATEX | No |
| Pump | Bare |
| Max flow rate | 100 l/min - 90 l/min |
| Orifice | 1"1/4 M |
| Materials | PVDF |
| Mechanism | Hastelloy C |
