MO-B-44C1, MO-B-44C2, MO-B-44, MO-B-45
Offset rotor pumps with bronze pump body
Applications: Water, sea water, diesel, oil
Offset rotor pumps with bronze pump body
Descriptive
Technical data:
- Pump body: bronze
- Motor: 0.55 kW, 1400 rpm
- Max. viscosity: 500 cPo
- Suction capacity: 3 metres
- Orifice Ø: 1’’
- Motor: 0.37 to 1.5 kW (DS20.1 range), 0.75 to 1.5 kW
- Max. pressure: 3.5 bars
- Hard particles: 3.2 millimetres
- Soft particles: 6.4 millimetres
Specifications and advantages:
Helical screw electric pumps with bronze bodies, mostly used in the maritime industry for transfers on ships: waste tankers, waste water discharges from toilets, heavy liquids with suspended solid particles, viscous and oily liquids such as lubricant oils, waste oils, fuel oil, diesel, etc.
Characteristics
| Fluid | Water with low solids contect, Seawater, Fluids with particulates, Diesel, Oil |
|---|---|
| Technology | DC, Eccentric rotor |
| ATEX | No |
| Pump | Bare |
| Max flow rate | 2,8 m3/h |
| Orifice | 1’’ |
| Materials | Bronze |
| Mechanism | NBR |
